Condition:Used

Key Specifications

Display & Hardware:

• Screen Size: 12.1″ TFT LCD (typically XGA resolution – 1024×768)

• Touchscreen: 5-wire resistive (alternatively may feature projective capacitive depending on variant)

• Processor: Intel Core i5/i7 (exact generation varies by revision)

• Memory: Up to 8GB DDR3 RAM (expandable)

• Storage: 64GB SSD (industrial-grade)

• Front Panel: IP65/NEMA 4X protection

Communication Interfaces:

• Standard Ports:

  • 2× Gigabit Ethernet (10/100/1000 Mbps)

  • 4× USB (2.0/3.0)

  • 1× DisplayPort

  • 1× RS-232/485 (software configurable)

• Expansion Options:

  • PCI/PCIe slots (via backplane)

  • Fieldbus interfaces (PROFIBUS, CANopen, etc. via modules)

Software Environment:

• Operating System: Windows Embedded Standard 7/10 or real-time B&R Automation Runtime

• Development Platform: B&R Automation Studio (v4.x+)

• Protocol Support: POWERLINK, OPC UA, Modbus TCP, EtherNet/IP

Environmental Ratings:

• Operating Temp: 0°C to +50°C (with SSD)

• Storage Temp: -40°C to +85°C

• Humidity: 10-95% non-condensing

• Vibration: 1G (5-150Hz)

• Shock: 15G (11ms duration)

Power Supply:

• Input Voltage: 24V DC (-15%/+20%)

• Power Consumption: ~60W typical

• Backup: Supercapacitor for safe shutdown

Model Number Breakdown (5AP112.0702-C04 Rev D0):

• 5AP112: Panel PC 2200 series

• 0702: Hardware configuration code

• C04: Display/touchscreen variant

• D0: Revision level (hardware improvements)

Key Features:

1. Multi-touch Operation: Supports gesture control (if capacitive version)

2. Industrial Certification: UL, CE, cULus

3. Real-time Performance: <1ms cycle times with Automation Runtime

4. Secure Boot: UEFI secure boot capability

5. Redundant Storage: RAID support available

Typical Applications:

• Machine visualization and control

• Packaging systems

• Printing presses

• Semiconductor manufacturing

• Energy management systems
